PLC Controlled Hanging Rod Type Batch Off Cooler with Adjustable Configuration and Temperature Control

Product Categories
Qingdao Shun Cheong Rubber machinery Manufacturing Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

PLC Controlled Hanging Rod Type Batch Off Cooler with Adjustable Configuration and Temperature Control

Brand Name : SFC

Model Number : XPG-600

Certification : CE、ISO9001、SGS

Place of Origin : China

MOQ : 1

Price : US$5000.00-59999.00/set

Payment Terms : L/C,T/T

Supply Ability : 500sets/year

Delivery Time : 60 days

Packaging Details : Safety wood or plywood crates packaging.

Control System : PLC

Material : Carbon Steel/Stainless Steel

Operation Mode : Automatic

Product Name : Rubber Batch Off Cooler

Voltage : 380V

Warranty : 1 Year

Weight : Customized

Contact Now

Hanging Rod Type Batch Off Cooler & Rubber Batch Off Machine
The Hanging Rod Type Batch Off Cooler and Rubber Batch Off Machine provides controlled cooling and solidification of rubber compounds, ensuring products maintain their shape, dimensions, and quality before further processing or packaging.
Key Features
  • Precision Temperature Control: Advanced temperature control mechanisms regulate the cooling process to maintain rubber compound physical properties and prevent deformation
  • Efficient Conveyor System: Automated conveyor system transports cooled rubber sheets away from hanging rods for continuous processing and efficient handling
  • Adjustable Configuration: Customizable spacing between hanging rods accommodates various sheet thicknesses with controlled conveyor speed to match production rates
PLC Controlled Hanging Rod Type Batch Off Cooler with Adjustable Configuration and Temperature Control PLC Controlled Hanging Rod Type Batch Off Cooler with Adjustable Configuration and Temperature Control PLC Controlled Hanging Rod Type Batch Off Cooler with Adjustable Configuration and Temperature Control PLC Controlled Hanging Rod Type Batch Off Cooler with Adjustable Configuration and Temperature Control PLC Controlled Hanging Rod Type Batch Off Cooler with Adjustable Configuration and Temperature Control PLC Controlled Hanging Rod Type Batch Off Cooler with Adjustable Configuration and Temperature Control PLC Controlled Hanging Rod Type Batch Off Cooler with Adjustable Configuration and Temperature Control PLC Controlled Hanging Rod Type Batch Off Cooler with Adjustable Configuration and Temperature Control PLC Controlled Hanging Rod Type Batch Off Cooler with Adjustable Configuration and Temperature Control PLC Controlled Hanging Rod Type Batch Off Cooler with Adjustable Configuration and Temperature Control PLC Controlled Hanging Rod Type Batch Off Cooler with Adjustable Configuration and Temperature Control
Technical Specifications
Model XPG-600 XPG-800 XPG-900
Max Rubber Sheet Width 600 mm 800 mm 900 mm
Rubber Sheet Thickness 4-10 mm 4-10 mm 6-12 mm
Temperature Reduction 5℃ above room temp 5℃ above room temp 5℃ above room temp
Conveyor Linear Speed 3-35 m/min 3-35 m/min 4-40 m/min
Hanging Bar Speed 1-3 m/min 1-3 m/min 1-3 m/min
Hanging Bar Height 1000 mm 1400 mm 1400 mm
Cooling Fans 0-24 sets 25-52 sets 24-60 sets
Total Power 16-32 kW 20-63 kW 25-70 kW
Dimensions 12400×2140×2820 mm 14850×2220×2860 mm 18000×2300×2980 mm
Contact Information
Business Manager: Ayla
Email: sales-6@sfcjx.com
Company Profile
Qingdao Shun Cheong Rubber Machinery Manufacturing Co., Ltd is a high-technology backbone enterprise specializing in rubber machinery production, located at Kangting Road No. 1, West Coast New District, Qingdao, China. The company holds ISO9001:2015 quality management system certification, European Union CE certification, and Switzerland SGS certification.
Industry Coverage
Tire manufacturing, rubber conveyor belt production, various rubber products, tire refurbished manufacturing, and waste tire recycling.
Main Equipment
Rubber Kneader, Rubber Mixing Machine, Rubber Vulcanizing Press, Batch Off Cooler, Rubber Calender, Waste Tire Crusher, Rubber Extruder, Rubber Strainer, and more.
Global Reach
Products exported to over 50 countries including Britain, Switzerland, USA, Germany, Brazil, Singapore, Malaysia, India, Russia, Ukraine, Uzbekistan, and Kazakhstan, earning consistent customer praise and long-term cooperation.
Quality Commitment
  • All components undergo strict quality inspection before storage
  • Comprehensive pre-shipment testing including 24-hour pressure testing at 1.25x rated working pressure for vulcanizing presses
  • Lifetime free technical support for all products
  • 3-year warranty on main parts, 1-year warranty on wearing parts
  • Immediate remote support with on-site engineering assistance when needed
