High Quality Eva Foaming Vulcanizer / Eva Foaming Vulcanizing Press

Brand Name : SFC

Model Number : XLB-1200X1200X4

Certification : CE, ISO

Place of Origin : Qingdao, China

MOQ : 1 set

Price : US$10,000.00

Payment Terms : T/T,L/C

Supply Ability : 500 set/year

Delivery Time : 25-35 days

Contact Now

Product Description


EVA Foaming Vulcanizing Press,Rubber Machine,Foaming Sheet Rubber Press

1. High quality plate press
2. Beautiful modeling, Compact structure
3. Completive price
4. High speed open/close mold, high production efficiency, protect mold.
5. Its structure is simpleand application is wide. It is easy to be operated
6. We can provide hand control and electric control as customer's request.

Application;
1. This machine is mainly used for producing various EVA foam slippers, foam sheet, insulation materials, sports protective material, life jackets, sponges and other thermos rubber products.
2. Advantageous Features: Small temperature difference, reliable pressure performance, automatically pressure compensation during curing processMain frame use cast steel, piston adapt chilled cast iron, with surface rigidity of H-R-70.
3. Qingdao Shun Cheong Machinery Co., Ltd. Your trusted partner

Note:
1. Its product range includes EVA MID-soles, rainboots, slippers, sandals, clogs, sport protectors and various kinds of shoes and shoe accessories and depends on the EVA shoe mould.
2. The clamping force can be increased from 150 to 210 tons, according to your requirement.
3. The foam EVA injection molding machine is fully hydraulic and automatic operation except taking out product.
4. It is PLC controlled, its humanized parameter computer operation interface provide quick and exact terms of production.

Character:
1. Low operation height, Operation height in accord with human engineering
2. Extra height opening stroke
Act by fixed opening stroke: 350mm, which is not affected by any mould thickness changes and
3. Available for 2plates mould, Mould thickness adjusting mechanism
Mould adjusting scope: 100-200MM
4. Rapid mould opening, Act by toggle mechanism which opens the mould rapidly
5. Speedy injector movement
Driven by linear-track, allowing speedy moving and precise positioning, Energy saving design
6. No need water circulation for mould station
7. Space saving design, Put oil tank together with injection base, which makes the structure compact and saves more space.
Main Parameter:

Parameter/Type
XLB-Q 1200x1200x4 XLB-Q 1400x1500x6 XLB-Q 1500x1500x6
Total Pressure (MN) 5.0 8.0 10.0
Plate Size (mm) 1200x1200 1400x1500 1500x1500
Plate Clearance (mm) 150 150 150
Piston Stroke(mm) 500 800 150
Plate Unit Pressure(Mpa) 3.4 3.8 4.5
Main Motor Power(KW) 18.5 26 33
Dimension (mm) 2400x2100x3200 2650x2400x3600 2750x2400x3600
Weight (kg) 22000 38000 48000
All staffs in Qingdao Shun Cheong Machinery Co., Ltd are willing to provide first-class technology, quality, service and cost-effective rubber processing equipment for customers at home and abroad. And also we sincerely welcome customers at home and abroad to come and have a visit at our company to negotiate and guide.


High Quality Eva Foaming Vulcanizer / Eva Foaming Vulcanizing PressHigh Quality Eva Foaming Vulcanizer / Eva Foaming Vulcanizing Press

High Quality Eva Foaming Vulcanizer / Eva Foaming Vulcanizing Press

High Quality Eva Foaming Vulcanizer / Eva Foaming Vulcanizing PressHigh Quality Eva Foaming Vulcanizer / Eva Foaming Vulcanizing Press

High Quality Eva Foaming Vulcanizer / Eva Foaming Vulcanizing PressHigh Quality Eva Foaming Vulcanizer / Eva Foaming Vulcanizing Press

WhatsApp: +8618344700139High Quality Eva Foaming Vulcanizer / Eva Foaming Vulcanizing Press
Email: rubbermachine@sfcjx.com
Origin: Jiaonan, Qingdao, China
Production Capacity: 500 Sets/Year
Qingdao Shun Cheong Machinery Co., Ltd provides first-class technology, quality service, and cost-effective rubber processing equipment for domestic and international customers.
