XLB-800X600 Rubber Plate Vulcanizing Press Machine
Product Overview
Plate vulcanizing machine is specialized machinery for producing various rubber products and thermosetting plastic items including sealing products, projected rubber, and rubber plates.
- Available in three frame types: frame type, pillar type, and jaw type (for round rubber products)
- Features compact structure, high working pressure, and excellent production efficiency
- Safe and reliable operation with customizable sizes, types, and operation methods
Technical Specifications
| Model |
Total Pressure |
Daylight |
Working Layer |
Piston Stroke |
Main Motor Power |
Overall Diameter |
| XLB-350*350*2 | 0.25 | 125 | 2 | 250 | 2.2 | 1200*580*1200 |
| XLB-400*400*2 | 0.50 | 125 | 2 | 250 | 2.2 | 1400*500*1400 |
| XLB-600*600*2 | 1.00 | 125 | 2 | 250 | 2.2 | 1880*820*1680 |
| XLB-750*850*4 | 1.60 | 125 | 4 | 500 | 3 | 1730*930*2460 |
| XLB-900*900*2 | 2.5 | 200 | 2 | 400 | 4 | 2345*960*1385 |
| XLB-1200*1200*1 | 3.15 | 300 | 1 | 300 | 4 | 2800*1300*2300 |
| XLB-1300*2000*1 | 5.60 | 400 | 1 | 400 | 8 | 2000*1860*2500 |
| XLB-1500*1500*1 | 8.00 | 800 | 1 | 800 | 16.5 | 2200*2200*4300 |
| XLB-1500*2500*1 | 15.00 | 400 | 1 | 400 | 11 | 3000*2500*3300 |
| XLB-2000*2000*1 | 20.00 | 400 | 1 | 400 | 11 | 3600*3000*3300 |
Machine Construction & Features
- Composed of press plate, up and down platform, piston stroke, hydro-cylinder, hydraulic station, and pillar column
- Hot plates made from 35# steel plates with normalizing treatment and double scale rolling
- Up and down platforms use Q235 steel plates with precision manufacturing including automatic cutting, mechanical slicing, and CO₂ gas shielded welding
- Cylinder material: QT500-7 with HT200 piston (alternative: ZG270-500 cylinder with cold hard chilled alloy cast iron piston)
- Sealing structure uses combined double sealing ring and one dustproof ring for extended service life
- Piston movement controlled by hydraulic pressure with gravity-assisted return system
- Assembled oil pump provides power source with manual control via hand shank
- Electrical control system offers automatic and semi-automatic operation modes with manual override capability
Frequently Asked Questions
Delivery time of the rubber machines?
Custom-designed machines require 25-35 days from engineering design to production completion.
What does your factory do regarding quality control?
Comprehensive quality control throughout production process. Every machine is fully assembled and tested before shipment.
What's the machine quality guarantee?
One-year quality guarantee using world-famous brand components for optimal performance.
Are you able to give installation and commissioning overseas?
Yes, we provide overseas service and technical support (customer covers installation costs). Small machines: 2-3 days; Large plants: ~30 days.
How can I trust you to deliver the right machine as I ordered?
We maintain company culture based on innovation, quality, integrity and efficiency. We have established relationships with world-renowned rubber manufacturers.
How can we go to your side?
Located in Qingdao City, Shandong province, China (Qingdao Liuting airport). We provide airport pickup service.
Packaging & Shipping
Equipment is painted before delivery and wrapped with stretch film to protect surface finish. Custom wooden packaging available. Key components like electronic control boxes use shockproof materials in wooden cases.
Our team includes 15 experienced engineers and 108 skilled workers ensuring timely delivery. We maintain long-term cooperation with COSCO for reliable port arrivals.
Our rubber vulcanizing presses have been exported to America, Mexico, India, Vietnam, South Africa, Singapore, Malaysia, Indonesia, Australia, Sri Lanka and many other countries.
